High frequency blister packaging machine



First, [product name] rotary type high frequency blister packaging machine

Second, [product model] ZH-8000A

Third, [main use] blister packaging, blowing toys, raincoats, rainbags, handbags, stationery stickers, leather embossing, paper card blister sealing

Fourth, [product introduction]

A. Features of the whole machine:

1. Using vacuum tube, the output power is stable and reliable.

2. Highly sensitive spark overcurrent protection circuit. It can automatically cut off high-frequency suppression sparks.

3. High frequency frequency stabilizer and high frequency shielding device are provided to minimize high frequency interference.

4. Set the manual adjustment mold to facilitate the test mode.

5. Automatically complete the welding process to improve the efficiency of the work.

6. Stepless temperature regulation heating system, welding is faster.

7. Four-level horizontal adjustment, easy to adjust the mold.

8. Safety protection requires an automatic over-pressure over-current spark protection system to increase the life of the vacuum tube. Protect the mold from damage.

9.4kw40.68MHz. 5-12kw27.12MHz international standard industrial band.

10. Taiwan "CKC" time system, precise lock setting time.

11. Taiwan high pressure silicon tube.

12. Taiwan "AIRTAC" pneumatic components.

13. Japan "OMRON" relay, micro switch.

14. Italy Promise Temperature Control System.

B. Scope of application:

It conforms to the 4th generation of European environmental protection standards and is mainly used for the molding of various plastic products, and automatically cuts the blister or blister of different shapes. Suitable for TPU.PVC double-sided blister sealing, blister and paper card sealing, environmentally friendly APET film folding, soft line indentation die-cutting, environmental protection APET double-sided blister seal when trimming the contract, special material sealing . Blister packaging (including hot and cold trimming of upper and lower double blister, heat sealing and trimming of blister and cardboard), plastic cover, various packaging bags, blister packaging, blowing toys, raincoat raincoat, leather handbag, stationery sticker, leather embossing , footwear trademarks, car seat cushions, cloth embossing, PVC folding boxes, etc. Any TPU.PVC or PVC with a plastic content of 30% or more.

C, technical parameters:

Model MODEL ZH-8000A

High cycle output Output Power 8000W

Power input Input Power 12KVA

Power voltage 220V or 380V volts adjusted according to instructions

Oscillation rate Oscillation 27.12MHz

Rectifier Rectifier Silicon Diode

Pressed Way of pressure

Oscillation tube 7T69RB

Fixed size SIize of dise 600×800

Upper and lower electrode spacing Gap ofeletr 250

Mechanical Size Size of machine 1000/720/1860

Institutional activity distance from Machine move distance 200

Machine weight Weight of machine 500kg
