Product Name: High power single tank ultrasonic cleaning machine
Product model: ZH-1024ST
ZH-1024 single tank ultrasonic cleaning machine
◆Inner groove size: L × W × H (mm) 580 × 400 × 400
Dimensions: L × W × H (mm) 720 × 540 × 695
◆Material: It is made of imported SUS304δ2.0mm stainless steel plate, the vibration surface is made of SUS304δ2.5mm stainless steel plate, and the outer plate is made of stainless steel plate.
◆Structure: The whole machine is equipped with 1〝 drainage ball valve at the bottom of the moving caster, 24 vibrating vibrators at the bottom/50W, the ultrasonic power is
1200W (power adjustable), frequency 28KHz/40KHz, the whole machine is all stainless steel structure.
◆Ultrasonic heating system: It is heated by stainless steel heating plate, heating power is 2KW, mechanical automatic constant temperature control 30~110°C is adjustable.
◆Electrical system: electrical components are imported high quality parts
◆Ultrasonic generator: digital frequency synthesis technology under microcomputer control, continuous adjustment of ultrasonic power (digital display)
Complete protection: overheating, overcurrent protection, and a four-digit timer to make time control accurate to the second.
With sweep function.
◆Power supply: Ultrasonic 220V/50Hz Heating power supply 380v/50Hz
◆Configuration: one cylinder head and one washing basket
◆ Scope of application: Hardware, electronics, watches, machinery, tools, glasses, jewelry, semiconductor wafers, polyester spinnerets and polyester filters and glassware.
Note: Various non-standard model sizes can be customized according to customer requirements!
